MAROLOLIFT Hydraulic lift 1000 HA

In stock

Lift design for groundcare vehicles

* Required Fields

Log in to view prices

Log in to view prices

Details

Groundcare Lift MAROLOLIFT Hydraulic 1000 HA

  • Lift designed for groundcare vehicles
  • Robust conception for heavy-duty use
  • Central gate to increase access for the technician to cutting system
  • Run-up ramps in checker plate and adjustable from 512 to 1 100 mm, including wheel stop is in up position (CE standard)
  • Robust hydraulic jack (diameter 60 mm / 2.4 '') with safety valve integrated (CE standard)
  • Mechanical safety ensured by dog in rack (8 positions)
  • Only one energy for all connections
  • CE CERTIFIED
  • Inground version available
Table élévatrice motoculture 1000 HA

More Views

Specifications



SPECIFICATIONS
  REFERENCE     MODELE   CONTROL UNIT    HEIGHT      LENGHT     WIDTH    CAPACITY
 CENTRAL TRAP DOOR
ENERGY  SAFETY   WEIGHT

804100

1001 HA

Foot pump

1000 mm

39,4 ''

2120 mm

83,5 ''

1100 mm

43 ''

500 Kg

1100 lbs

700 x 400 mm

27,5 x 15,7 ''

-

Mecanic with

rack and dog

210 Kg

462 lbs

804101

1002 HA

hydro-pneumatic

pump

1000 mm

39,4 ''



2120 mm

83,5 ''

1100 mm

43 ''



500 Kg

1100 lbs


700 x 400 mm

27,5 x 15,7 ''

Pneumatic

8 Bar

Mecanic with

rack and dog



205 Kg

452 lbs


804102 1000 HA Electric pump

1000 mm

39,4 ''



2120 mm

83,5 ''


1100 mm

43 ''

500 Kg

1100 lbs

700 x 400 mm

27,5 x 15,7 ''



Electric

230 V - 50 Hz



Mecanic with

rack and dog

215 Kg

474 lbs
